| ชื่อแบรนด์: | UOTEK |
| เลขรุ่น: | UT-60020G |
| ขั้นต่ำ: | 1 |
| ราคา: | สามารถต่อรองได้ |
| Product Model | Optical Ports | Ethernet Ports | Optical Port Type |
|---|---|---|---|
| UT-60020G-16GT-BNF | - | 16-channel | - |
| UT-60020G-16GT4GSC-BNF | 4-channel | 16-channel | SC Optical Port |
| UT-60020G-16GT4GP-BNF | 4-channel | 16-channel | SFP Slot |
| Protocol Standards | IEEE802.3, IEEE802.3u, IEEE802.3z, IEEE802.3ab |
|---|---|
| Interfaces | Fiber Optic: 1000Base-X port (SC/ST/FC/SFP slot) RJ45: 10/100/1000Base-T(X) port, MDI/MDI-X auto-sensing |
| Transmission Distance | Category 5e twisted pair: 100m Fiber Optic: Single-mode 1310nm 20-120Km, Multimode 1310nm 2km |
| Switching Performance | Forwarding Rate: 1,488,095pps Transmission Mode: Store-and-Forward MAC Address Cache: 8K Backplane Bandwidth: 40G |
| Power Requirements | Input Voltage: 12/24/48VDC (10.8-52.8VDC) Supports redundant dual power input Power Consumption: 15W rated |
| Mechanical Characteristics | Housing: IP40 protection Weight: ≤1600g Installation: DIN rail mounting Dimensions: 150×70×120mm (W×H×D) |
| Operating Environment | Operating Temperature: -40℃ to 75℃ Storage Temperature: -40℃ to 85℃ Relative Humidity: 0-95% (non-condensing) |
| Industry Standards | EMI: FCC Part 15, CISPR (EN55022) class A EMS: IEC(EN)61000-4-2 to 4-8, IEC 60068-2-27, IEC 60068-2-32 |
