| ชื่อแบรนด์: | Emerson |
| เลขรุ่น: | KJ3241X1-BA1 VE4009 |
| ขั้นต่ำ: | 1 |
| ราคา: | Negotiations |
Fisher Rosemount Systems, Emerson Process Management, Ltd
This Serial Interface uses Terminal Block KJ4006X1-BD1 (12P4722X052)
| Catalog Description | Simplex SIC (Serial Interface Card), LocalBus Power Rating 12 VDC 300mA |
|---|---|
| Ambient Temperature | -40 to 70℃ |
| Alternate Part Numbers | SE4006P2, SE4036P2, 12P4710X062, KJ3241X1BK1 |
| Common Typographical Errors | None |
| Shock | 10g ½ Sinewave for 11 msec |
|---|---|
| Vibration | 1mm Peak to Peak from 5 to 16Hz; 0.5g from 16 to 150Hz |
| Airborne Contaminants | ISA-S71.04-1985 Airborne Contaminants Class G3 |
| Relative Humidity | 5 to 95% Non-Condensing IP 20 Rating |
| Terminal | Block key position D4 |
Traditional I/O is a modular subsystem that offers flexibility during installation. It's designed to be installed in the field, near your devices. Traditional I/O is equipped with function and field wiring protection keys to ensure that the correct I/O card is always plugged into the corresponding terminal block.
Modularity, protection keys, and plug-and-play capabilities make DeltaV™ Traditional I/O a smart choice for your process control system.
