| ชื่อแบรนด์: | ABB |
| เลขรุ่น: | DO821 |
| ขั้นต่ำ: | 1 |
| ราคา: | Negotiations |
| Attribute | Value |
|---|---|
| Potentiometer Rated Insulation Voltage | 50V |
| Dielectric Test Voltage | 500VAC |
| Current Consumption +5 V Modulebus | 70mA |
| Power Dissipation | 1.6W |
230 V a.c./d.c. (5-250 V a.c./d.c.), 3 A DO821 | 3BSE013250R1 Digital Output Module
| Type | Digital Output |
| Signal specification | 230 V a.c./d.c. (5-250 V a.c./d.c.), 3 A |
| Article number | 3BSE013250R1 |
| Number of channels | 8 |
| Signal type | Relay (NC) |
| HART | No |
| SOE | No |
| Redundancy | No |
| High integrity | No |
| Intrinsic safety | No |
| Mechanics | S800 |
| Isolation | Individually isolated, channel-to-channel and to circuit common |
| Current limiting | Can be current limited by the MTU |
| Maximum field cable length | 600 meters (656 yards) |
| Rated insulation voltage | 250 V |
| Dielectric test voltage | 2000 V a.c. |
| Power dissipation | Typ. 2.9 W |
| Current consumption +5 V Modulebus | 60 mA |
| Current consumption +24 V Modulebus | 140 mA |
| Current consumption +24 V external | 0 |
| CE mark | Yes |
| Electrical safety | IEC 61131-2, UL 508 |
| Hazardous Location | - |
| Marine certification | ABS, BV, DNV-GL, LR, RS, CCS |
| Protection rating | IP20 according to IEC 60529 |
| Corrosive atmosphere ISA-S71.04 | G3 |
| Climatic operating conditions | 0 to +55 °C (Storage -40 to +70 °C), RH=5 to 95 % no condensation, IEC/EN 61131-2 |
| Pollution degree | Degree 2, IEC 60664-1 |
| Mechanical operating conditions | IEC/EN 61131-2 |
| EMC | EN 61000-6-4, EN 61000-6-2 |
| Overvoltage categories | IEC/EN 60664-1, EN 50178 |
| Equipment class | Class I according to IEC 61140; (earth protected) |
| Max ambient temperature | 55 °C (131 °F), for vertical mounting in compact MTU 40 °C (104 °F) |
| RoHS compliance | EN 50581:2012 |
| WEEE compliance | DIRECTIVE/2012/19/EU |
| Front LED's | F(ault), R(un), W(arning), O(SP), Channel 1-8 Status |
| Supervision | 24 / 12 V Relay power converter monitor |
| Status indication of supervision | Module Error, Module Warning, Channel error |
