| ชื่อแบรนด์: | Mitsubishi |
| เลขรุ่น: | QD77MS4 |
| ขั้นต่ำ: | 1 |
| ราคา: | Negotiations |
| Attribute | Value |
|---|---|
| Product Type | MELSEC-Q QD77MS Simple Motion Module |
| Number Of Control Axes | 4 Axes |
| Flash ROM Write Count Max | 100000 Times |
The QD77M4 is a high-performance Mitsubishi Electric motion controller module designed for precise multi-axis positioning control in industrial automation systems. It integrates seamlessly with Mitsubishi's MELSEC iQ-R Series PLCs, offering advanced motion control capabilities, high-speed response, and flexible synchronization for complex machinery. Ideal for applications requiring accuracy, repeatability, and reliability, the QD77M4 supports up to 4 axes of servo control with real-time monitoring and diagnostics.
| Parameter | Specification | Unit/Notes |
|---|---|---|
| Control Method | SSCNET III/H | Fiber-optic communication |
| Number of Axes | 4 | Independent/synchronized control |
| Positioning Accuracy | ±1 pulse or better | Depends on servo resolution |
| Maximum Speed | 10,000,000 pulses/sec (per axis) | Varies by servo motor |
| I/O Points | 32 inputs / 32 outputs (configurable) | Digital signals |
| Power Supply | 24V DC (±10%) | 0.8A typical consumption |
| Operating Temperature | 0°C to +55°C | Storage: -25°C to +75°C |
| Vibration Resistance | 5.9 m/s² (10-55 Hz) | JIS B 3502 compliant |
| Certifications | CE, UL, cUL, RoHS | Industrial standards |
