Intelligent Axial Displacement Monitoring / Protection Device

Intelligent Axial Displacement Monitoring / Protection Device

  • Intelligent Axial Displacement Monitoring / Protection Device
  • Intelligent Axial Displacement Monitoring / Protection Device
Intelligent Axial Displacement Monitoring / Protection Device
รายละเอียดสินค้า:
Place of Origin: China
ชื่อแบรนด์: OEM
Model Number: JM-X-3W & JM-X-3Z
การชำระเงิน:
Minimum Order Quantity: 1 set
Packaging Details: Wooden box packing
Delivery Time: 15 days after signing the contract
Payment Terms: T/T
Supply Ability: 1000sets
ติดต่อ
รายละเอียดสินค้า
แสงสูง:

electronic measuring devices

,

turbine speed sensor

Intelligent Axial Displacement Monitoring / Protection Device



JM-X-3W Intelligent Axial Displacement Monitoring and Protection Device & JM-X-3Z Intelligent Expansion Difference Monitoring and Protection Device

Use

This device mainly applies to continuous monitoring and measuring of displacement values,such as axial displacement,expansion difference,and etc,it can automatically give alarm signals,protective shut-down signals and 4-20 mA current output.

Functions

1.Highly lntelligent,all parameters can  be set on a control panel.

2.Suitable for on-line monitoring for a long time,easy to install and debug,needing no site mintenance;

3.2 level alarm switch output.

4.4~20mA analog current output.

5.Free configurations of measuring range,alarm and danger value.

6.Alternative probe installation direction,

7.Adjusable probe installation zero point.

8.Passwort protection on parameter configuration.

9.Automatic record of emergency shut-down operations.

10.Automatic detection of off-line.

11.Automatic record and inquirie of maximum sample value.

Technical  parameters

1.Dispaly mode:4 digit 0.8 inch digital LED display.

2.Measuring range :JM-X-3W axial displacement measuring range

                                CWY-DO-Ф 8mm eddy current sensor:-1.00~+1.00mm

                                CWY-DO-Ф 11mm eddy current sensor:-2.00~+2.00mm

                                JM-X-3Z expansion difference measuring range

                                CWY-DO-Ф 18mm eddy current sensor:-3.00~+5.00mm

                                 CWY-DO-Ф 25mm eddy current sensor:-4.00~+6.00mm

3.Measuring accuracy:±0.5 class,linear error≤1%FS

4.lnput signal:CWY-DO eddy current sensor

5.Output signals:Current:4~20mA(load≤1kΩ)

                           2level switch output :DC 27V/2A or AC250V/5A

6.lnstallation thread :Φ8mm eddy current sensor M10×1.0mm

                                 Φ11mm eddy current sensor M14×1.5mm

                                 Φ18mm eddy current sensor M25×1.5mm

                                 Φ25mm eddy current sensor M30×2.0mm

7.Environmental temperature:-10~65℃(Relative humidity:≤85%)

8.Power voltage:AC 220V/50Hz±10%

9.LNSTALLATION:Disk

10.External dimensions:95mm(height)×170mm(length)×260mm(depth)

11.Hole size:77mm(height)×152mm(length)
