Meanwell DRT-240-48 240W Three Phase Industrial DIN RAIL Power Supply high reliability

Meanwell DRT-240-48 240W Three Phase Industrial DIN RAIL Power Supply high reliability

ชื่อแบรนด์: MEAN WELL
เลขรุ่น: DRT-240-48
ขั้นต่ำ: 2 sets
เงื่อนไขการจ่ายเงิน: T/T
ความสามารถในการจําหน่าย: 1000sets
ข้อมูลรายละเอียด
Place of Origin:
China
MODEL:
DRT-240-24
DC VOLTAGE:
48V
CURRENT RANGE:
0 ~ 5A
VOLTAGE ADJ. RANGE:
48 ~ 55V
Packaging Details:
Wooden box packing
Supply Ability:
1000sets
เน้น:

electrical protective devices

,

dc power contactor

คําอธิบายสินค้า

Original SE-100-24 24V/4.5A Single Output AC to DC High-power Switching Power Supply



Features :

  • Three-phase AC340-550V wide range input
  • High efficiency 89% and low dissipation
  • Protection : short circuit / overload / over voltage / over temperature
  • Cooling by free air convection
  • Built-in constand current limiting circuit
  • Can be installed on DIN rail  TS-35/7.5  or 15
  • UL508 ( industrial control equipment ) approved
  • EN61000-6-2 ( EN50082-2)  indusctrial immunity level
  • 100% full load burn-in test
  • Fixed switching frequency at 70KHZ
  • 3 Years warranty
MODEL DRT-240-24
OUTPUT DC VOLTAGE 24V
RATED CURRENT 10A
RATED POWER 240W
RIPPLE & NOISE (max.) Note.2 80mVp-p
VOLTAGE ADJ. RANGE 24~28V
VOLTAGE TOLERANCE Note.3v ±1.0%
LINE REGULATION ±0.5%
LOAD REGULATION ±0.5%
SETUP.RISE TIME 1200ms, 40ms, 20ms/400VAC 800ms, 40ms, 40ms/500VAC at full load
INPUT VOLTAGE RANGE Note.5 Three-Phase 340 ~ 550VAC (Dual phase operation possible) 480 ~ 780VDC
FREQUENCYRANGE 47~63HZ
EFFICIENCY (Typ.) 89%
AC CURRENT (Typ.) 0.95A/400VAC 0.75A/500VAC
INRUSH CURRENT (max.) COLD START 50A
PROTECTION OVERLOAD 105 ~ 150% rated output power
Protection type : Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE 30 ~ 36V

Protection type : Shut down o/p voltage, re-power on to recover







Mechanical specification ( In mm)





Meanwell DRT-240-48 240W Three Phase Industrial DIN RAIL Power Supply high reliability 0
